High quality Components
At Nirvana, the quality of our products is a priority. Our goal is to provide a worry-free experience. Designed to perform even in the northern climes, the units are manufactured with high-end parts that allow for an exceptionally long product life. A Corrosion protection coating is also applied inside the heat pumps to ensure the proper functioning of components over time.
Extremely quiet.
The pursuit of quiet operation of our heat pumps is a constant endeavour for Nirvana, several innovations are already included in our design to reduce the noise level. The compressor’s acoustic cover, the design of the fan blades and the reinforced composite cabinet substantially limits the noise nuisance. That being said, the Nirvana heat pumps maintain a sound level that varies from 53 to 57 decibels.
Precise and user-friendly digital Control Panel.
The Nirvana digital control panel allows you to adjust temperature of the pool water with precision, thus ensuring a constant water temperature while maximising the energy efficiency of the heat pump. The Nirvana heat pump is also compatible with pool management systems or with our wireless control option.
Functional and Aesthetic design.
In addition of its role of noise reduction, the reinforced composite casing of the Nirvana heat pump offers several advantages. Specially designed for an easy maintenance, it was also conceived to allow a quick and simple installation. The casing won’t fade, is corrosion resistant and is of unparalleled robustness. It is so well built that we provide a 15 years warranty on it.
| TECHNICAL DATA | Above Ground Models | Inground | ||||||
|---|---|---|---|---|---|---|---|---|
| MODELS | TR30 – 110Volt | TR45 | TR65-70 | TR95 | TR115 | TR135 | TR135HC | |
| (80/80/80 – AHRI) 1 | BTU | 27 500 | 41 000 | TBA | 95 000 | 115 000 | 135 000 | 133 000 |
| COP | 6.1 | 5.7 | 6.0 | 6.0 | 5.9 | 5.9 | ||
| (80/63/80 – AHRI) 1 | BTU | 26 000 | 39 000 | 90 000 | 111 000 | 129 000 | 128 000 | |
| COP | 5.9 | 5.4 | 5.8 | 5.8 | 5.8 | 5.8 | ||
| (50/63/80 – AHRI) 1 | BTU | 18 000 | 26 000 | 000 | 78 000 | 85 000 | 84 000 | |
| COP | 4.1 | 3.8 | 4.1 | 4.1 | 4.1 | 4.1 | ||
| COMBINED WITH A SILENSOR PUMP | BTU | 31 500 | 45 000 | 95 000 | 115 000 | 133 000 | 132 000 | |
| COP | 6.4 | 6.1 | 6.1 | 6.0 | 5.9 | 5.9 | ||
| REFRIGERANT | R410A | |||||||
| MINIMUM / MAXIMUM BREAKER | 20 | 20/30 | TBA | 40/50 | 40/50 | 50/60 | 50/60 | |
| AMPS | 10.7 | 10.3 | TBA | 15.5 | 117.57 | 23.7 | 27.5 | |
| DECIBEL AT 10 M | 44 | 42 | TBA | 42 | 43 | 43 | 45 | |
| VENTILATION | 26’’ SINGLE SPEED 825 RPM | |||||||
| HEAT EXCHANGER | TITANIUM-DOUBLE COIL | |||||||
| AMPS | PASSIVE (46F) | |||||||
| CONTROL BOARD | DIGITAL 4 LINES X 20 CHARACTERS | |||||||
| COMPRESSOR TYPE | Rotary | SCROLL | ||||||
| VOLTAGE | 120V plug in | 240V / 60HZ / 1 PHASE | ||||||
| CASING | INJECTED POLYPROPYLENE COMPOSITE REINFORCED WITH FIBERGLASS | |||||||
| WATER FLOW (GPM) | 20-80 | 20-80 | 26-80 | 32-80 | 40-80 | 40-80 | 40-80 | |
| DIMENSIONS (INCHES) (W X L X H) | 39 X 37 X 30 | 39 X 37 X 30 | 39 X 37 X 38 | 39 X 37 X 38 | 39 X 37 X 38 | 39 X 37 X 42 | 39 X 37 X 42 | |
| WEIGHT (LBS) | 185 | 191 | 222 | 241 | 245 | 250 | 255 | |
| WATER CONNECTION | 2” – QUICK CONNECT FITTINGS – INCLUDED | |||||||
| POOL DIMENSIONS | ABOVE GROUND | 12’-15’-18’ | 15’-18’-21’ | 21’-24’ | 24’ – 2 7’ | 27’ | N/A | N/A |
| INGROUND | 10 X 16 | 10’ X 20’ | 12’ X 24’ | 14’ X 28’ | 16’ X 30’ | 16’ X 34’ | 18’ X 36’ | |
| 10’ X 20’ | 12’ X 24’ | 14’ X 28’ | 16’ X 30’ | 16’ X 32’ | 18’ X 36’ | 20’ X 40’ | ||
