Get the most out of your pool heating investment!
- High performance titanium heat exchanger
- Microprocessor controlled defrost cycle allows operation down to mid to low 40s °F
- Built-in drain pan for condensate management
- Impact resistant, rust and fade proof cabinet
- Quieter than conventional heat pumps
- NEW Smart Microprocessor Control with LCD Display
- Flip-out, lockable control panel is protected against sun and weather and can be easily programmed to prevent others from tampering with settings
- Digital control panel with 24 character full-text display provides easy-to-read menu options and unit status
- Ability to connect to most external controllers
- Hybrid functionality can initiate a gas heater when an extra boost of heat is needed.
Specs
| BTUs (water temp/ambient air/relative humidity) |
T75 |
|---|---|
| 80/80/80 | 74,000 |
| 80/80/63 | 70,000 |
| 80/50/63 | 49,000 |
|
Coefficient of Performance (water temp/ambient air/relative humidity) |
|
| 80/80/80 | 5.6 |
| 80/80/63 | 5.4 |
| 80/50/63 | 4.0 |
| Refrigerant | R410A |
| Heat Exchanger | Tube in Tube |
| Electrical | |
| KW Input | 3.9 |
| Voltage/Hz/Phase | 208-230/60/1 |
| Minimum Circuit Ampacity | 31.4 |
| Maximum Fuse Size | 50 |
| *Over Temperature Alarm Kit available: part number STK0221 for single phase, STK0222 for three phase. Strongly recommended for all spa applications. | |
| Water Flow | |
| Minimum/Maximum (gpm) | 20/45 |
| *A Heater Bypass Kit is required when flow rates exceed the maximum: part number STK0135. | |
| Physical | |
| Weight (lbs) | 200 |
| Size (LxWxH) | 34″ x 34″ x 28″ |
| Shipping | |
| Weight (lbs) | 240 |
| Size (LxWxH) | 38″ x 36″ x 33″ |
